The GREEN RANGE S SXF is a fully TR2009-certified training cartridge for use by law enforcement, which was specially engineered for police training requirements. The deformation bullet is turned from solid brass and has a weight of 6.1 g. It also describes the same trajectory as the ACTION 4 SXF and ACTION 5 SXF tactical cartridges. The special bullet geometry significantly reduces the risk of ricochets. The 9x19 GREEN RANGE S is lead free and has minimised emissions, which makes it the ideal product for use in indoor shooting ranges. In addition, the cartridge’s excellent reliability makes it suitable for use with fully automatic submachine guns.
![[Translate to English:]](/resources/public/user_upload/Images/Artikel/Geschossgraphiken-9mm/9x19-GREEN-RANGE-S-SXF.png "[Translate to English:]")
Product line ACTION
9x19 GREEN RANGE S SXF
6.1 g / 94 gr
Product characteristics
- Articlenumber*
- 2318664
- Product line
- ACTION
- Caliber
- 9x19
- Purpose
- Law enforcement
- Bulletweight (g)
- 6.1 g
- Bulletweight (gr)
- 94 gr
- Bullet type
- Solid
- Bullet material
- Brass
- Leadfree
- Yes
- Primer cap
- SINTOX Forensis
- Case material
- Brass
- Propellant powder
- Two-base nitrocellulose powder
- Total cartridge mass (g)
- ca. 10.1 g
- Net explosive mass (g)
- ca. 0.4 g
- Weapon category
- Pistol, Submachine gun
- Temperature range
- -20°C to +52°C
*article number for the smallest packaging unit
Data according to technical delivery terms
- Mean gas pressure
- max. 2,700 bar (21°C)
- Velocity measuring point
- v3
- Velocity (m/s)
- 415 m/s
- Velocity (ft/s)
- 1,362 ft/s
- Energy (J)
- 525 J
- Length test barrel
- 100 mm
- Velocity measuring point tolerance (± m/s)
- 15 ± m/s
Precision data
- Accuracy type
- sa
- Accuracy determination range (m)
- 25 m
- Precision requirement
- ≤ 25 mm
- Length test barrel
- 100
- Barrel length:
- 104 mm
- Twist length:
- 250 mm (1:10")
Ballistic data – Pistol
- Velocity measuring point type I
- v3
- Velocity (m/s)
- 414 m/s
- Weapon category
- Pistol
| Distance (m) | Velocity (m/s) | Energy (J) | Flight time (ms) | Ballistic coefficient G1 |
|---|---|---|---|---|
| 0 | 414 | 523 | 0 | |
| 25 | 398 | 483 | 25 | 0,104 |
| 50 | 384 | 450 | 50 | 0,112 |
| 100 | 358 | 391 | 104 | 0,107 |
| 150 | 337 | 346 | 162 | 0,108 |
| 200 | 321 | 314 | 223 | 0,115 |
| 250 | 310 | 293 | 286 | 0,124 |
| 300 | 301 | 276 | 352 | 0,166 |
| 350 | 295 | 265 | 419 | 0,197 |
| 400 | 288 | 253 | 487 | 0,158 |
| 450 | 281 | 241 | 557 | 0,128 |
| 500 | 272 | 226 | 630 | 0,105 |
| 550 | 262 | 209 | 705 | 0,084 |
| 600 | 251 | 192 | 783 | 0,07 |
- Barrel length:
- 225 mm
- Twist length:
- 254 mm (1:10")
Ballistic data – Submachine gun
- Velocity measuring point type I
- v3
- Velocity (m/s)
- 414 m/s
- Weapon category
- Submachine gun
| Distance (m) | Velocity (m/s) | Energy (J) | Flight time (ms) | Ballistic coefficient G1 |
|---|---|---|---|---|
| 0 | 462 | 651 | 0 | |
| 25 | 444 | 601 | 22 | 0,108 |
| 50 | 427 | 556 | 45 | 0,109 |
| 100 | 395 | 476 | 94 | 0,107 |
| 150 | 368 | 413 | 146 | 0,11 |
| 200 | 345 | 363 | 203 | 0,107 |
| 250 | 327 | 326 | 262 | 0,11 |
| 300 | 314 | 301 | 325 | 0,127 |
| 350 | 304 | 282 | 390 | 0,138 |
| 400 | 297 | 269 | 456 | 0,177 |
| 450 | 291 | 258 | 524 | 0,188 |
| 500 | 284 | 246 | 594 | 0,151 |
| 550 | 275 | 231 | 665 | 0,109 |
| 600 | 266 | 216 | 739 | 0,096 |
